| Basic Information |
Mercedes-Benz EQB 2025 EQB260 |
| Manufacturer |
Beijing Benz-EQ |
| level |
Compact SUV |
| Energy Type |
Pure Electric |
| Availability |
2024-08-01 |
| CLTC pure electric cruising range [km] |
600 |
| Fast charging time [min] |
45 |
| Fast charge capacity[%] |
10-80 |
| Slow charging time [hours] |
10.25 |
| Slow charging capacity[%] |
0-100 |
| Motor [Ps] |
190 |
| Gearbox |
1st gear fixed gear ratio |
| Length*width*height[mm] |
4684*1834*1693 |
| Body structure |
5-door 5-seater SUV |
| Maximum speed [km/h] |
160 |
| Official 0-100km/h acceleration [s] |
8.8 |
| Power consumption per 100 km [kWh/km] |
13.2 |
| Vehicle warranty |
3 years unlimited mileage |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
4684 |
| Width [mm] |
1834 |
| Height [mm] |
1693 |
| Wheelbase[mm] |
2829 |
| Front wheel track[mm] |
1587 |
| Rear track [mm] |
1585 |
| Door opening method |
Swing door |
| Number of doors |
5 |
| Seating capacity |
5 |
| Approach angle [°] |
19 |
| Departure angle [°] |
twenty three |
| Minimum turning radius [m] |
- |
| Drag coefficient [Cd] |
0.28 |
| Official trunk volume [L] |
1620 |
| Curb weight[kg] |
2072 |
| Full load mass [kg] |
2520 |
| Electric Motor |
|
| Motor brand |
ZF |
| Motor Model |
EM0026 |
| Number of drive motors |
Single motor |
| Motor layout |
Pre |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
140 |
| Total motor horsepower [Ps] |
190 |
| Total torque of the motor [N·m] |
380 |
| Maximum power of front motor [kW] |
140 |
| Maximum torque of front motor [N·m] |
380 |
| Maximum power of rear motor [kW] |
- |
| Maximum torque of rear motor [N·m] |
- |
| Battery/Energy Recharge |
|
| Battery Type |
Ternary lithium battery |
| Battery brand |
Farasis Energy |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
600 |
| Battery capacity [kWh] |
73.5 |
| Battery energy density [Wh/kg] |
188 |
| Power consumption per 100 km [kWh/km] |
13.2 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
● Left rear side of the vehicle |
| Fast charging port location |
●Right rear side of the vehicle |
| High voltage fast charging platform |
●400V platform |
| Fast charging power [kW] |
- |
| Fast charging time[min] |
45 |
| Fast charging time[h] |
0.75 |
| Fast charge capacity[%] |
10-80 |
| Slow charging power [kW] |
7 |
| Slow charging time[h] |
10.25 |
| Slow charging capacity[%] |
0-100 |
| Vehicle battery replacement |
- |
| Home charging station |
● |
| On-board charging gun |
○Optional 2900 yuan
|
| External discharge function |
- |
| Battery Pack Warranty |
8 years or 160,000 km |
| Gearbox |
|
| Gearbox Description |
Electric vehicle single speed gearbox |
| Gearbox Type |
Fixed gear ratio |
| Number of gears |
1 |
| Chassis steering |
|
| Drive type |
Front front drive |
| Four-wheel drive |
- |
| Central differential structure |
- |
| Front suspension type |
McPherson independent suspension |
| Rear suspension type |
Multi-link independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
- |
| Adjustable suspension type |
- |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
Solid disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
●235ናR18○235R19 6200 yuan
|
| Rear tire specifications |
●235ናR18○235R19 6200 yuan
|
| Spare tire |
No spare tire |
