| Basic Information |
Formula Leopard 5 2025 1.5T 125km Tianshen Intelligent Driving Ultra Edition |
| Manufacturer |
Formula Leopard |
| level |
Mid-size SUV |
| Energy Type |
Plug-in hybrid |
| Environmental standards |
National VI |
| Availability |
2025-02-21 |
| CLTC pure electric cruising range [km] |
125 |
| Fast charging time [minutes] |
16 |
| Fast charge capacity[%] |
30-80 |
| engine |
1.5T194HPL4 |
| Maximum power [kW] |
143 |
| Maximum torque [N·m] |
273 |
| Motor [Ps] |
660 |
| Gearbox |
Electronic Continuously Variable Transmission (E-CVT) |
| Length*width*height[mm] |
4890*1970*1920 |
| Body structure |
5-door 5-seater SUV |
| Maximum speed [km/h] |
180 |
| Official 0-100km/h acceleration [s] |
4.8 |
| WLTC comprehensive fuel consumption [Lkm] |
1.81 |
| WLTC low-power fuel consumption [Lkm] |
7.8 |
| Power consumption per 100 km [kWhkm] |
twenty four |
| Vehicle warranty |
6 years or 150,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
4890 |
| Width [mm] |
1970 |
| Height [mm] |
1920 |
| Wheelbase [mm] |
2800 |
| Front wheel track[mm] |
1660 |
| Rear track [mm] |
1660 |
| Door opening method |
Swing door |
| Number of doors |
5 |
| Seating capacity |
5 |
| Approach angle [°] |
35 |
| Departure angle [°] |
32 |
| Pass angle [°] |
20 |
| Maximum climbing grade [%] |
- |
| Minimum ground clearance when fully loaded [mm] |
220 |
| Fuel tank capacity [L] |
83 |
| Curb weight[kg] |
2890 |
| Full load mass [kg] |
3265 |
| Traction mass [kg] |
2500 |
| engine |
|
| Engine Model |
BYD476ZQF |
| Displacement [mL] |
1497 |
| Displacement [L] |
1.5 |
| Air intake form |
Turbocharger |
| Engine layout |
Vertical |
| Cylinder arrangement |
L |
| Number of cylinders |
4 |
| Number of valves per cylinder |
4 |
| Valve mechanism |
DOHC |
| Maximum power [kW] |
143 |
| Maximum horsepower [Ps] |
194 |
| Maximum torque [N·m] |
273 |
| Maximum net power [kW] |
135 |
| Fuel grade |
No. 92 |
| Oil supply method |
Direct Injection |
| Cylinder head material |
Aluminum Alloy |
| Cylinder material |
Aluminum Alloy |
| Environmental standards |
National VI |
| Electric Motor |
|
| Motor Model |
Front TY220XYAB/Rear TZ200XYA |
| Number of drive motors |
Dual motors |
| Motor layout |
Front + rear |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
485 |
| Total motor horsepower [Ps] |
660 |
| Total torque of the motor [N·m] |
760 |
| Maximum power of front motor [kW] |
200 |
| Maximum torque of front motor [N·m] |
360 |
| Maximum power of rear motor [kW] |
285 |
| Maximum torque of rear motor [N·m] |
400 |
| System total power [kW] |
505 |
| System comprehensive horsepower [Ps] |
687 |
| System comprehensive torque [N·m] |
760 |
| Battery/Energy Recharge |
|
| Battery Type |
Lithium iron phosphate battery |
| Battery brand |
Fudi |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
125 |
| NEDC comprehensive range [km] |
1200 |
| Battery capacity [kWh] |
31.8 |
| Power consumption per 100 km [kWhkm] |
twenty four |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
●Right rear side of the vehicle |
| Fast charging port location |
●Right rear side of the vehicle |
| Fast charging power [kW] |
100 |
| Fast charging time[min] |
16 |
| Fast charging time[h] |
0.27 |
| Fast charge capacity[%] |
30-80 |
| Slow charging power [kW] |
6 |
| Vehicle battery replacement |
- |
| On-board charging gun |
● |
| External discharge function |
● |
| VTOL external discharge power |
6kW |
| Battery Pack Warranty |
8 years or 150,000 km |
| First Owner Battery Pack Warranty |
Unlimited years/unlimited mileage (liability exemption clauses are subject to official regulations) |
| Gearbox |
|
| Gearbox Description |
E-CVT continuously variable transmission |
| Gearbox Type |
Electronic Continuously Variable Transmission (E-CVT) |
| Number of gears |
- |
| Chassis steering |
|
| Drive type |
Front four-wheel drive |
| Four-wheel drive |
Electric four-wheel drive |
| Center differential structure |
- |
| Front suspension type |
Double wishbone independent suspension |
| Rear suspension type |
Double wishbone independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
- |
| Adjustable suspension type |
- |
| Vehicle structure |
Non-load bearing |
| Limited slip differential |
- |
| Differential lock |
●Rear axle ○Front axle |
| Maximum wading depth [mm] |
700 |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
●Ventilated disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
●265/65 R18○275/55 R20 |
| Rear tire specifications |
●265/65 R18○275/55 R20 |
| Spare tire |
Full size |
| Spare tire placement |
Backpack |
| Spare tire |
No spare tire |
