| Basic Information |
XIA 2025 DM-i1.5T100km Exceeding Type |
| Manufacturer |
BYD New Energy |
| level |
Medium and large MPV |
| Energy Type |
Plug-in hybrid |
| Environmental standards |
National VI |
| Availability |
2025-01-08 |
| CLTC pure electric cruising range [km] |
100 |
| WLTC pure electric range [km] |
80 |
| Fast charging time [minutes] |
18 |
| Fast charge capacity[%] |
30-80 |
| Slow charging time [hours] |
3.1 |
| Slow charging capacity[%] |
15-100 |
| engine |
1.5T156HPL4 |
| Maximum power [kW] |
115 |
| Maximum torque [N·m] |
225 |
| Motor [Ps] |
272 |
| Gearbox |
Electronic Continuously Variable Transmission (E-CVT) |
| Length*width*height[mm] |
5145*1970*1805 |
| Body structure |
5-door 7-seater MPV |
| Maximum speed [km/h] |
190 |
| Official 0-100km/h acceleration [s] |
8.1 |
| WLTC comprehensive fuel consumption [Lkm] |
2.07 |
| WLTC low-power fuel consumption [Lkm] |
6.4 |
| NEDC low-power fuel consumption [Lkm] |
5.3 |
| Power consumption per 100 km [kWhkm] |
18.5 |
| Vehicle warranty |
6 years or 150,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
5145 |
| Width [mm] |
1970 |
| Height [mm] |
1805 |
| Wheelbase [mm] |
3045 |
| Front track [mm] |
1676 |
| Rear track [mm] |
1683 |
| Door opening method |
Hinged door + sliding door |
| Number of doors |
5 |
| Seating capacity |
7 |
| Approach angle [°] |
14 |
| Departure angle [°] |
16 |
| Minimum ground clearance when fully loaded [mm] |
140 |
| Minimum turning radius [m] |
5.7 |
| Fuel tank capacity [L] |
50 |
| Official trunk volume [L] |
470-2036 |
| Curb weight[kg] |
2470 |
| Full load mass [kg] |
3045 |
| engine |
|
| Engine Model |
BYD472ZQB |
| Displacement [mL] |
1498 |
| Displacement [L] |
1.5 |
| Air intake form |
Turbocharger |
| Engine layout |
Sideways |
| Cylinder arrangement |
L |
| Number of cylinders |
4 |
| Number of valves per cylinder |
4 |
| Valve mechanism |
DOHC |
| Maximum power [kW] |
115 |
| Maximum horsepower [Ps] |
156 |
| Maximum power speed [rpm] |
5500 |
| Maximum torque [N·m] |
225 |
| Maximum torque speed [rpm] |
2500-4500 |
| Maximum net power [kW] |
110 |
| Fuel grade |
No. 92 |
| Oil supply method |
Direct Injection |
| Cylinder head material |
Aluminum Alloy |
| Cylinder material |
Aluminum Alloy |
| Environmental standards |
National VI |
| Electric Motor |
|
| Motor Brand |
BYD |
| Motor Model |
TZ210XYD |
| Number of drive motors |
Single motor |
| Motor layout |
Pre |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
200 |
| Total motor horsepower [Ps] |
272 |
| Total torque of the motor [N·m] |
315 |
| Maximum power of front motor [kW] |
200 |
| Maximum torque of front motor [N·m] |
315 |
| Battery/Energy Recharge |
|
| Battery Type |
Lithium iron phosphate battery |
| Battery brand |
Fudi |
| Battery Temperature Management |
●Low temperature heating ●Refrigerant cooling |
| CLTC pure electric range [km] |
100 |
| WLTC pure electric range [km] |
80 |
| CLTC comprehensive endurance [km] |
- |
| Battery capacity [kWh] |
20.39 |
| Battery energy density [Wh/kg] |
102 |
| Power consumption per 100 km [kWhkm] |
18.5 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
●Right rear side of the vehicle |
| Fast charging port location |
●Right rear side of the vehicle |
| Fast charging power [kW] |
41 |
| Fast charging time[min] |
18 |
| Fast charging time[h] |
0.3 |
| Fast charge capacity[%] |
30-80 |
| Slow charging power [kW] |
7 |
| Slow charging time[h] |
3.1 |
| Slow charging capacity[%] |
15-100 |
| Vehicle battery replacement |
- |
| External discharge function |
● |
| VTOL external discharge power |
6kW |
| First Owner Battery Pack Warranty |
Unlimited years/unlimited mileage (liability exemption clauses are subject to official regulations) |
| Gearbox |
|
| Gearbox Description |
E-CVT continuously variable transmission |
| Gearbox Type |
Electronic Continuously Variable Transmission (E-CVT) |
| Number of gears |
- |
| Chassis steering |
|
| Drive type |
Front front drive |
| Four-wheel drive |
- |
| Central differential structure |
- |
| Front suspension type |
McPherson independent suspension |
| Rear suspension type |
Multi-link independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
●Soft and hard adjustment |
| Adjustable suspension type |
- |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
●Ventilated disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
235/60 R18 |
| Rear tire specifications |
235/60 R18 |
| Spare tire |
No spare tire |
