| Basic Information |
Li L7 2024 L7Ultra |
| Manufacturer |
Li Automobile |
| level |
Medium and large SUV |
| Energy Type |
Extended range pure electric |
| Environmental standards |
National VI |
| Availability |
2024-03-01 |
| CLTC pure electric cruising range [km] |
286 |
| WLTC pure electric range [km] |
240 |
| Fast charging time [minutes] |
25 |
| Fast charge capacity[%] |
20-80 |
| Slow charging time [hours] |
7.9 |
| Slow charging capacity[%] |
0-100 |
| engine |
1.5T154HPL4 |
| Maximum power [kW] |
113 |
| Maximum torque [N·m] |
245 |
| Motor [Ps] |
449 |
| Gearbox |
1st gear fixed gear ratio |
| Length*width*height[mm] |
5050*1995*1750 |
| Body structure |
5-door 5-seater SUV |
| Maximum speed [km/h] |
180 |
| Official 0-100km/h acceleration [s] |
5.3 |
| WLTC low-power fuel consumption [Lkm] |
7.4 |
| Power consumption per 100 km [kWhkm] |
22.8 |
| Vehicle warranty |
5 years or 100,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
5050 |
| Width [mm] |
1995 |
| Height [mm] |
1750 |
| Wheelbase [mm] |
3005 |
| Front wheel track[mm] |
1725 |
| Rear track [mm] |
1741 |
| Door opening method |
Swing door |
| Number of doors |
5 |
| Seating capacity |
5 |
| Approach angle [°] |
19 |
| Departure angle [°] |
twenty one |
| Fuel tank capacity [L] |
65 |
| Official trunk volume [L] |
801 |
| Curb weight[kg] |
2500 |
| Full load mass [kg] |
3130 |
| engine |
|
| Engine Model |
Range Extender L2E15M |
| Displacement [mL] |
1496 |
| Displacement [L] |
1.5 |
| Air intake form |
Turbocharger |
| Engine layout |
Sideways |
| Cylinder arrangement |
L |
| Number of cylinders |
4 |
| Number of valves per cylinder |
4 |
| Compression ratio |
12.5 |
| Valve mechanism |
DOHC |
| Maximum power [kW] |
113 |
| Maximum horsepower [Ps] |
154 |
| Maximum power speed [rpm] |
4800 |
| Maximum torque [N·m] |
245 |
| Maximum torque speed [rpm] |
2500-4000 |
| Maximum net power [kW] |
110 |
| Fuel grade |
No. 95 |
| Oil supply method |
Direct Injection |
| Cylinder head material |
Aluminum Alloy |
| Cylinder material |
Aluminum Alloy |
| Environmental standards |
National VI |
| Electric Motor |
|
| Motor Model |
Front TZ180XS008/Rear TZ220XS066 |
| Number of drive motors |
Dual motors |
| Motor layout |
Front + rear |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
330 |
| Total motor horsepower [Ps] |
449 |
| Total torque of the motor [N·m] |
620 |
| Maximum power of front motor [kW] |
130 |
| Maximum torque of front motor [N·m] |
220 |
| Maximum power of rear motor [kW] |
200 |
| Maximum torque of rear motor [N·m] |
400 |
| System total power [kW] |
330 |
| System comprehensive horsepower [Ps] |
449 |
| System comprehensive torque [N·m] |
620 |
| Battery/Energy Recharge |
|
| Battery Type |
Ternary lithium battery |
| Battery brand |
CATL |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
286 |
| WLTC pure electric range [km] |
240 |
| CLTC comprehensive endurance [km] |
1421 |
| WLTC comprehensive range [km] |
1185 |
| Battery capacity [kWh] |
52.3 |
| Power consumption per 100 km [kWhkm] |
22.8 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
●Right rear side of the vehicle |
| Fast charging port location |
●Right rear side of the vehicle |
| High voltage fast charging platform |
●400V platform |
| Fast charging power [kW] |
90 |
| Fast charging time[min] |
25 |
| Fast charging time[h] |
0.42 |
| Fast charge capacity[%] |
20-80 |
| Slow charging power [kW] |
7 |
| Slow charging time [h] |
7.9 |
| Slow charging capacity[%] |
0-100 |
| Vehicle battery replacement |
- |
| Home charging station |
○Optional 5000 yuan |
| On-board charging gun |
- |
| External discharge function |
● |
| VTOL external discharge power |
3.5kW |
| Battery Pack Warranty |
8 years or 160,000 km |
| Gearbox |
|
| Gearbox Description |
Electric vehicle single speed gearbox |
| Gearbox Type |
Fixed gear ratio |
| Number of gears |
1 |
| Chassis steering |
|
| Drive type |
Dual motor four-wheel drive |
| Four-wheel drive |
Electric four-wheel drive |
| Center differential structure |
- |
| Front suspension type |
Double wishbone independent suspension |
| Rear suspension type |
Five-link independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
●Height adjustment ●Softness and hardness adjustment |
| Adjustable suspension type |
Air suspension |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
●Ventilated disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
265/45 R21 |
| Rear tire specifications |
265/45 R21 |
| Spare tire |
No spare tire |
