| Basic Information |
AITO M9 2024 pure electric version 630kmUltra 5 seats |
| Manufacturer |
AITOAITO |
| level |
Large SUV |
| Energy Type |
Pure Electric |
| Environmental standards |
- |
| Availability |
2024-09-10 |
| CLTC pure electric cruising range [km] |
630 |
| WLTC pure electric range [km] |
- |
| Fast charging time [min] |
15 |
| Fast charge capacity[%] |
30-80 |
| Slow charging time [hours] |
11.7 |
| Slow charging capacity[%] |
20-90 |
| engine |
- |
| Maximum power [kW] |
- |
| Maximum torque [N·m] |
- |
| Motor [Ps] |
530 |
| Gearbox |
1st gear fixed gear ratio |
| Length*width*height[mm] |
5230*1999*1800 |
| Body structure |
5-door 5-seater SUV |
| Maximum speed [km/h] |
200 |
| Official 0-100km/h acceleration [s] |
4.3 |
| WLTC comprehensive fuel consumption [Lkm] |
- |
| WLTC low-power fuel consumption [Lkm] |
- |
| Power consumption per 100 km [kWhkm] |
17.4 |
| Vehicle warranty |
4 years or 100,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
5230 |
| Width [mm] |
1999 |
| Height [mm] |
1800 |
| Wheelbase[mm] |
3110 |
| Front track [mm] |
1707 |
| Rear track [mm] |
1713 |
| Door opening method |
Swing door |
| Number of doors |
5 |
| Seating capacity |
5 |
| Approach angle [°] |
18 |
| Departure angle [°] |
20 |
| Minimum turning radius [m] |
5.8 |
| Drag coefficient [Cd] |
0.264 |
| Fuel tank capacity [L] |
- |
| Official trunk volume [L] |
1043-2486 |
| Curb weight[kg] |
2560 |
| Full load mass [kg] |
3010 |
| engine |
|
| Engine Model |
- |
| Displacement [mL] |
- |
| Displacement [L] |
- |
| Air intake form |
- |
| Engine layout |
- |
| Cylinder arrangement |
- |
| Number of cylinders |
- |
| Number of valves per cylinder |
- |
| Compression ratio |
- |
| Valve mechanism |
- |
| Maximum power [kW] |
- |
| Maximum horsepower [Ps] |
- |
| Maximum power speed [rpm] |
- |
| Maximum torque [N·m] |
- |
| Maximum torque speed [rpm] |
- |
| Maximum net power [kW] |
- |
| Fuel grade |
- |
| Oil supply method |
- |
| Cylinder head material |
- |
| Cylinder material |
- |
| Environmental standards |
- |
| Electric Motor |
|
| Motor brand |
Huawei Technologies |
| Motor Model |
Front YS210XYA03/Rear TZ210XYA03 |
| Number of drive motors |
Dual motors |
| Motor layout |
Front + rear |
| Motor Type |
Front AC asynchronous/rear permanent magnet synchronous |
| Total motor power [kW] |
390 |
| Total motor horsepower [Ps] |
530 |
| Total torque of the motor [N·m] |
673 |
| Maximum power of front motor [kW] |
160 |
| Maximum torque of front motor [N·m] |
277 |
| Maximum power of rear motor [kW] |
230 |
| Maximum torque of rear motor [N·m] |
396 |
| Battery/Energy Recharge |
|
| Battery Type |
Ternary lithium battery |
| Battery brand |
CATL |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
630 |
| WLTC pure electric range [km] |
- |
| CLTC comprehensive endurance [km] |
- |
| WLTC comprehensive range [km] |
- |
| Battery capacity [kWh] |
100 |
| Power consumption per 100 km [kWhkm] |
17.4 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
● Left rear side of the vehicle |
| Fast charging port location |
● Left rear side of the vehicle |
| High voltage fast charging platform |
●800V platform |
| Energy replenishment speed |
5 minutes of charging, 150 km of energy |
| Fast charging time[min] |
15 |
| Fast charging time[h] |
0.25 |
| Fast charge capacity[%] |
30-80 |
| Slow charging power [kW] |
7 |
| Slow charging time[h] |
11.7 |
| Slow charging capacity[%] |
20-90 |
| Vehicle battery replacement |
- |
| Home charging station |
○ |
| On-board charging gun |
- |
| External discharge function |
● |
| VTOL external discharge power |
6kW |
| Battery Pack Warranty |
8 years or 160,000 km |
| Gearbox |
|
| Gearbox Description |
Electric vehicle single speed gearbox |
| Gearbox Type |
Fixed gear ratio |
| Number of gears |
1 |
| Chassis steering |
|
| Drive type |
Dual motor four-wheel drive |
| Four-wheel drive |
Electric four-wheel drive |
| Central differential structure |
- |
| Front suspension type |
Double wishbone independent suspension |
| Rear suspension type |
Multi-link independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
●Height adjustment ●Softness and hardness adjustment |
| Adjustable suspension type |
Air suspension |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Maximum wading depth [mm] |
540 |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
●Ventilated disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
●265/45 R21○265/40 R22 |
| Rear tire specifications |
●285/45 R21○285/40 R22 |
| Spare tire |
●Tire repair tool only |
