| Basic Information |
ZEEKR MIX 2025 550km Intelligent Driving Edition |
| Manufacturer |
Zeekr |
| level |
Mid-size MPV |
| Energy Type |
Pure Electric |
| Availability |
2024-10-23 |
| CLTC pure electric range [km] |
550 |
| Fast charging time[h] |
0.175 |
| Fast charge capacity[%] |
10-80 |
| Motor [Ps] |
422 |
| Gearbox |
1st gear fixed gear ratio |
| Length*width*height[mm] |
4688*1995*1755 |
| Body structure |
5-door 5-seater MPV |
| Maximum speed [km/h] |
180 |
| Official 0-100km/h acceleration [s] |
6.8 |
| Vehicle warranty |
4 years or 100,000 km |
| First Owner Warranty Policy |
6 years or 150,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
4688 |
| Width [mm] |
1995 |
| Height [mm] |
1755 |
| Wheelbase[mm] |
3008 |
| Front wheel track[mm] |
1702 |
| Rear track [mm] |
1709 |
| Door opening method |
Casement door + swing door |
| Number of doors |
5 |
| Seating capacity |
5 |
| Approach angle [°] |
15 |
| Departure angle [°] |
19 |
| Minimum ground clearance when fully loaded [mm] |
165 |
| Minimum turning radius [m] |
4.95 |
| Official trunk volume [L] |
568-2000 |
| Curb weight[kg] |
2739 |
| Full load mass [kg] |
3150 |
| Electric Motor |
|
| Motor Brand |
Quzhou Jidian |
| Motor Model |
TZ235XYC01 |
| Number of drive motors |
Single motor |
| Motor layout |
Post |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
310 |
| Total motor horsepower [Ps] |
422 |
| Total torque of the motor [N·m] |
440 |
| Maximum power of rear motor [kW] |
310 |
| Maximum torque of rear motor [N·m] |
440 |
| Battery/Energy Recharge |
|
| Battery Type |
Lithium iron phosphate battery |
| Battery brand |
Quzhou Jidian |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
550 |
| Battery capacity [kWh] |
76 |
| Power consumption per 100 km [kWhkm] |
16.4 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
● Left rear side of the vehicle |
| Fast charging port location |
● Left rear side of the vehicle |
| High voltage fast charging platform |
●800V platform |
| Fast charging time[min] |
11 |
| Fast charging time[h] |
0.175 |
| Fast charge capacity[%] |
10-80 |
| Vehicle battery replacement |
- |
| Home charging station |
○ |
| On-board charging gun |
- |
| External discharge function |
● |
| VTOL external discharge power |
3.3kW |
| Battery Pack Warranty |
8 years or 200,000 km |
| First Owner Battery Pack Warranty |
Unlimited years/unlimited mileage (liability exemption clauses are subject to official regulations) |
| Gearbox |
|
| Gearbox Description |
Electric vehicle single speed gearbox |
| Gearbox Type |
Fixed gear ratio |
| Number of gears |
1 |
| Chassis steering |
|
| Drive type |
Rear-engine, rear-wheel drive |
| Four-wheel drive |
- |
| Center differential structure |
- |
| Front suspension type |
McPherson independent suspension |
| Rear suspension type |
Multi-link independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
●Soft and hard adjustment |
| Adjustable suspension type |
- |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
●Ventilated disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
●235/55 R19○235/50 R20 8000 yuan |
| Rear tire specifications |
255/50 R19 265/45 R20 |
| Spare tire |
No spare tire |
