| Basic Information |
AION RT 2025 650km Smart luxury Edition |
| Manufacturer |
Aion |
| level |
Mid-size car |
| Energy Type |
Pure Electric |
| Availability |
2024-11-06 |
| CLTC pure electric range [km] |
650 |
| Fast charging time[h] |
0.3 |
| Fast charge capacity[%] |
30-80 |
| Motor [Ps] |
224 |
| Gearbox |
1st gear fixed gear ratio |
| Length*width*height[mm] |
4865*1875*1520 |
| Body structure |
4-door 5-seater sedan |
| Maximum speed [km/h] |
163 |
| Official 0-100km/h acceleration [s] |
7.7 |
| Vehicle warranty |
4 years or 150,000 km |
| Appearance Color |
|
| Interior Color |
|
| Body |
|
| Length [mm] |
4865 |
| Width [mm] |
1875 |
| Height [mm] |
1520 |
| Wheelbase [mm] |
2775 |
| Front wheel track[mm] |
1602 |
| Rear track [mm] |
1606 |
| Door opening method |
Swing door |
| Number of doors |
4 |
| Seating capacity |
5 |
| Approach angle [°] |
14 |
| Departure angle [°] |
17 |
| Curb weight[kg] |
1750 |
| Full load mass [kg] |
2220 |
| Electric Motor |
|
| Motor brand |
Sharp Power |
| Motor Model |
TZ180XYXOF51 |
| Number of drive motors |
Single motor |
| Motor layout |
Pre |
| Motor Type |
Permanent magnet synchronous |
| Total motor power [kW] |
165 |
| Total motor horsepower [Ps] |
224 |
| Total torque of the motor [N·m] |
240 |
| Maximum power of front motor [kW] |
165 |
| Maximum torque of front motor [N·m] |
240 |
| Battery/Energy Recharge |
|
| Battery Type |
Lithium iron phosphate battery |
| Battery brand |
CATL |
| Battery Temperature Management |
●Low temperature heating ●Liquid cooling |
| CLTC pure electric range [km] |
650 |
| Battery capacity [kWh] |
68.1 |
| Power consumption per 100 km [kWhkm] |
11.9 |
| Vehicle charging port |
●Slow charging port●Fast charging port |
| Slow charging port location |
●Right front side of the vehicle |
| Fast charging port location |
●Right front side of the vehicle |
| High voltage fast charging platform |
●400V platform |
| Energy replenishment speed |
10 minutes of charging, 200 kilometers of energy |
| Fast charging time[min] |
18 |
| Fast charging time[h] |
0.3 |
| Fast charge capacity[%] |
30-80 |
| Vehicle battery replacement |
- |
| Home charging station |
○ |
| On-board charging gun |
- |
| External discharge function |
● |
| First Owner Battery Pack Warranty |
Unlimited years/unlimited mileage (liability exemption clauses are subject to official regulations) |
| Gearbox |
|
| Gearbox Description |
Electric vehicle single speed gearbox |
| Gearbox Type |
Fixed gear ratio |
| Number of gears |
1 |
| Chassis steering |
|
| Drive type |
Front front drive |
| Four-wheel drive |
- |
| Central differential structure |
- |
| Front suspension type |
McPherson independent suspension |
| Rear suspension type |
Torsion beam non-independent suspension |
| Power type |
Electric power assist |
| Adjustable suspension features |
- |
| Adjustable suspension type |
- |
| Vehicle structure |
Load-bearing |
| Limited slip differential |
- |
| Differential lock |
- |
| Wheel brake |
|
| Front brake type |
●Ventilated disc type |
| Rear brake type |
Solid disc type |
| Parking brake type |
Electronic parking brake |
| Front tire specifications |
●215/55 R17○235/45 R18 |
| Rear tire specifications |
●215/55 R17○235/45 R18 |
| Spare tire |
●Tire repair tool only |
